The series of products which Fujian HAOYO New Meterial Co.,LTD developed is solar panel glass self cleaning painting layer. After painting, the Nanoscale painting will fill the mini pores of glass and build a persistent layer on the top of glass.

This painting is transparent and with no change of the color of glass,almost no impact of the transmittance of sunlight.  The painting layer makes the surface of glass hard to be attached with dusts and sands

Self cleaning painting layer TY-100

Fujian HAOYO New Meterial Co.,LTD  developed a series of new products which is a Nanoscale painting layer to solve the cleaning issue of solar glass panel. The principle is to make the glass surface hydrophobic function. The painting layer makes the surface of glass hard to be attached with dusts and sands, as the rain falls, water will wash away the dusts and sands thoroughly. This function makes the glass maintain good transmittance, enhances generate electricity by harnessing solar energy.During the after cleaning works, it saves the difficulty and the time. This new material benefits solar energy plant.

Self cleaning painting layer principle: as the observed phenomenon, the rain falls onto the lotus leaf, and the water drops flow rapidly as many drops instead of staying on the leaf. The structure of lotus leaf surface is that many bump points are there and a lots of air fill the gap of bump points. The contact angle between water drop and the lotus leaf is more than 170°.And the rolling angle is minor than 2°. This is what we call the self cleaning function of nature.

The series of products which  Fujian HAOYO New Meterial Co.,LTD  developed is solar panel glass self cleaning painting layer. After painting, the Nanoscale painting will fill the mini pores of glass and build a persistent layer on the top of glass.

This painting is transparent and with no change of the color of glass,almost no impact of the transmittance of sunlight.  The painting layer makes the surface of glass hard to be attached with dusts and sands,which we call the self cleaning function.the thickness of painting is microns grade, excellent ACID and Alkali resistance, and UV resistance. Solar glass with painting layer performs better generating efficiency than the regular glass. The layer will also make the surface of glass better scratch resistance from dusts and sands, as well as the scratch of cleaning tools.

The series of products of self cleaning painting layer is good for the application of solar panel plants, solar energy generation factories and the after maintaining of solar energy industry.

Scope of application:

Applicable to various types of solar panel glass

Specifications:1L/5L/20L

Product performance:

The type of cleaning painting is mainly used for solar panel glass, can effectively the Nanoscale painting will fill the mini pores of glass and build a persistent layer on the top of glass combine to form a lasting protection layer, surface trace, does not affect the glass transmittance . The layer can effectively prevent from external invasion in the web of permeability and all kinds of pollution sources, excellent acid-proof alkaline, worth cement in the alkaline composition erosion effectively,. When in contact with food products after curing, no toxicity, not harmful to human body.

Method:

Painting instruction of TY-100

1. Must be dry, the glass surface is clean, keep the place well ventilated.

2. The protective agent directly with brush besmear to brush glass on the surface, crisscross full besmear to brush, shall not be omitted, brush glass surface should have certain protective agent for its absorption.Protective agent can handle per liter 4 to 10 square metre glass (depending on the glass absorption rate and on the surface of the case may be).

3. Under the protective agent, glass temperature has protective effect after 4 hours.Natural curing a week after the protective effect is best, 8 hours can not contact with rain.

4. This product can be in winter (below 0 ℃) in low temperature environment.But the cure time will be extended accordingly.Summer should prevent excessive exposure, glass result in very high surface temperatures (over 50 ℃) otherwise, reagent rate rise caused by dry too fast, and prevents the coating permeability.

5. The original packing seal storage life two years, two years later after the test protective effect is the same, still can continue to use.

The main technical parameters:

1. Appearance: colorless transparent oily liquid

2. Specific gravity: 0.73 to 0.79

3. Reference usage: (m2 / L) 4-10

4. The soil resistance: ★★★★★

5. Waterproof: ★★★★★

6. Paint: ★★★★★

7. Weather: ★★★★★

Note:

1. Suggest to paint small sample test, glass for at least 24 hours for the response.

2. Any contact with harsh chemicals and cleaning, may affect its useful life.

3. According to the inflammable material storage.

4. Keep out reach of children.

Emergency disposal:

1. The eyes rinse immediately with plenty of water after 15 minutes, and please accept the treatment of eye doctor.

2. Please accept the doctor diagnosed after eating.

3. Contact with skin, wash water and soap, please.

Production date: see the bottle
